39
PD-6 DVD Location Recorder (Chapter 3: Names and functions)
44.1/16
48/16
44.1/24
48/24
88.2/24
96/24
FS/24
SW
REC TR
2 4 5 6 2+4 1+5
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
Yes
Yes
Yes
Yes
No
No
Yes
Yes
Yes
Yes
No
No
Yes
Yes
Yes
Yes
No
No
Yes
Yes
Yes
Yes
No
No
INT
EXT
DIGITAL
23.976
24
25
29.97DF
29.97
30DF
30
2TR
4TR
5TR
6TR
2+4TR
1+5TR
See “Recording/playback” on page 70 for details about time code recording/
playback.
2. [FRAME] switch
Selects the time code frame rate for recording, playback and generation by the
internal TC generator.
American motion picture -0.1%
American motion picture
European film/PAL-SECAM video EBU
NTSC color with real time adjust
NTSC color
NTSC video/film
NTSC video/film
3. [CLOCK] switch
Selects the system master clock.
The internal clock is the master. “INT” is lit on the display.
The external word or video clock is the master. “EXT” is lit on the display.
The PD-6 automatically detects the clock type (word or video). When the PD-6 locks to a
word clock, “WORD” is lit. When it locks to a video clock, “VIDEO” is lit. When it does not
lock to the clock, “WORD” or “VIDEO” flashes and it runs with the internal clock reference.
The external clock available in the external digital signal is the master. “DIGI” is lit on the
display. When the PD-6 locks to a clock, “DIGITAL” is also lit on the display. When it does
not lock to the clock, “DIGITAL” flashes and it runs with the internal clock reference.
4. [FS/24] switch
Selects the Fs (sampling frequency) and Bit (quantization bit) for recording.
Depending on the setting, the available recording track modes change as follows.
5. [REC TR] select switch
Selects the recording track mode from among the following.
You can record to a stereo-track file.
You can record to a four-track file.
You can record to a five-track file.
You can record to a six-track file.
You can record to a two-track file and a four-track file simultaneously.
You can record to a mono-track file and a five-track file simultaneously.
