M3099EX/EH OEM Manual 3-59
INTERFACE
SPECIFICATIONS
Print information III register (Added to the Send Dither 3 command)
b7 b0
Character table No.
000 : FJ format (standard)
001 :
010 :
011 :
100 :
101 :
111 :
Reserved
Print data
b7 b0 b7 b0 b7 b0 b7 b0
Code1 Code2 Code40 40 bytes maximum
Print data format
ABCD %05ud
Character code (*1) Print code number (fixed) (*1) (*2)
The combination is as follows:
Example
ABCD
ABCD %05ud
%05ud
Combination
Only Character
Character + Print number
Only Print number
The sum of the number of the character codes and print code numbers
must not exceed 20 (digits).
% is a special command. If %% is specified, one % character is printed.
*1: These code must be in ASCI code.
*2: When you intend to print the number, please put '%05ud'. Then
the scanner prints the numbers in accordance with the information
of the resister of PRINT CONTROL command.
Printing number is only five figures.
