Extend control register #2
#2
b7
b0
[00h]
Transfer rate (front-side)
Transfer rate (back-side)
0
×××
: Depending on devices (800 ns)
1000:
Undefined
1001:
800 ns
1010:
Undefined
1011:
Undefined
1100:
Undefined
1101:
Undefined
1110:
Undefined
1111:
Undefined
•This register specifies the front-side and back-side image data
transfer rates.
0
×××
: Depending on devices
(800 /400ns change by EEPROM)
1000:
Undefined
1001:
800 ns
1010:
400 ns
1011:
Undefined
1100:
Undefined
1101:
Undefined
1110:
Undefined
1111:
Undefined
