M3099EX/EH OEM Manual B-5
SETUP MODE
User’s paper are classified in line-art scanning as follows:
The horizontal axis shows the background density/color of paper.
The vertical axis shows the density of character/line.
1 – 5 are the pattern number set
in setup mode.
1 : Normal background and
character.
2 : Normal background and
light character.
3 : Dark background and
normal-density character.
4 : Light character on red paper.
5 : Light character on green
paper.
(1) For patterns “1” to “5” when the power is turned on
Check that IPC-2 for front/back sides are installed during initialization.
If IPC-2 for either the front or back side is not installed, the scanner
regards as no setting obligatory and changes the memory of EEPROM.
(2) When IPC-2 pre-set is executed in setup mode
Check that IPC-2 for front/back sides are installed when the scanner
enters in IPC-2 pre-set.
If IPC-2 for either the front or back side is not installed, the scanner
does not enter in IPC-2 pre-set.
(3) When IPC-2 pre-set mode is executed
When IPC-2 pre-set mode is executed in online mode, the reading
parameter is valid or invalid (Host setting is invalid) as follows:
Background density Background color
Normal Dark Red Green Blue
Normal 1 3
Character
density
Light 2 4 5
