5 timing specification at binary output -13 – FUJITSU M3099EX/EH User Manual
Page 41
M3099EX/EH OEM Manual
3-13
INTERFACE
SPECIFICATIONS
MIN
TYP
MAX
t1
t2
t3
t4
t5
t6
t7
t8
700
500
500
100
100
100
100
2000
800
600
600
200
200
200
200
*1
900
700
700
300
300
300
300
[Standard transfer : front-side]
Unit : ns
MIN
TYP
MAX
t1
t2
t3
t4
t5
t6
t7
t8
300
100
100
100
100
100
100
2000
400
200
200
200
200
200
200
*1
500
300
300
300
300
300
300
[Fast transfer : back-side]
Unit : ns
Notes: 1. Timing marked with * varies according to the scanning
area.
Table 3.5 Timing specification at binary output
