CLEAR command
This command initializes the scanner and can be issued at any time.
b7
b0
CNT
(X‘03’)
b7
b0
CMD
(X‘44’)
b7
b0
CLEAR
command
CLEAR command details
b7
b0
00: POWER ON CLEAR
This command resets the system to the
power-on
status.
01: Control register clear
This command intitializes the operation
mode, image processing mode, and
subwindow mode. (*1)
10: Reading stop
This command stops operation during
(VGATE OFF, return) and ejects any
documents remaining in the ADF.
If this command is received after the front-
side is reading ends, the scanner is placed
in wait state.
*1: If a CONTROL REGISTER CLEAR command is issued after the
READ command is sent to the scanner but before the Read
Complete
is recieved from the scanner, a command sequence error occur.
Note: "Ready" is the response when this command ends normally.
