M3099EX/EH OEM Manual 3-47
INTERFACE
SPECIFICATIONS
X'0000' is set when the power is turned on or when a CLEAR
command is issued for initialization.
#7
#8
0 0 0 0 0 0
b7 b0 b7 b0
(*1)
Horizontal magnification
(When each direction zooming is valid)
0 0 0 0 1 1 0 0 1 : 25%
to to
0 0 1 1 0 0 1 0 0 : 100% (*2)
0
*1: Magnification is valid only when the horizontal/vertical zooming
specification (bit 1 of the register A#5) is set to "1".
*2: Document magnification has the following limitations:
Maximum main scanning data: 608 bytes/line
A
×
(B/400)
×
(C/100)
8
608 (bytes)
≤
A: Main scan width (unit: number of pixels when
scanned at 400 dpi)
B: Basic resolution (set from operator panel or control
register #0: 200, 240, 300, 400 dpi)
C: Horizontal magnification (25 to 100%)
This expression is rounded up to the integer.
Image control register B#5 to #8
Since these registers are not supported, specify X’08000000'.
