8-4 M3099EX/EH OEM Manual
Note:
Make sure that the following
lengths are the same:
a
1
= a
2
b
1
= b
2
Window
Window: transparent part
Cross-sectional view of lamp
and heater
a
1
a
2
b
1
b
2
Heater
7 Close the upper transport
unit. (See page 4-2)
Window
Front
6 To re-install lamp/heater,
reverse procedures in item
4 above.
Note:
When re-installing the lamp,
make sure to rotate the lamp in
the direction as shown in the
left figure.
Rear
Socket
