M3099EX/EH OEM Manual A-1
ENDORSER
APPENDIX
A
ENDORSER
Table A.1 lists the endorser specifications.
Table A.1 Endorser specifications
A1. Specifications
Item Specification
Printing method Ink jet printing method
Characters Alphabet: A to Z, a to z
Number : 0, 1, to , 9
Symbol : ! ” # $ % & ’ ( ) * + , – . / : ; < = > ?
@ [ ¥ ] ^ _ – { | } (blank)
Maximum number 20
of characters
Character size 2.9✕ 1.5 mm (0.11˝ ✕ 0.06˝) (hight ✕ width)
Character pitch Approx. 2.54 mm (0.1˝)
Print area Back-side of the document
A
≥
5 mm (0.2˝)
B
≥
28 mm (1.1˝)
C
≥
20 mm (0.79˝)
D
≥
5 mm (0.2˝)
Figure A.1 Print area
A
C
D
B
Read reference
position
Center of the
document
Feed direction
A
B
C
····S
T
(Back-side)
