FARGO electronic FARGO DTC 400 - Manual (Page 260)

RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400 Card Printer/Encoder User Guide (Rev. 2.6) 6-82
Selecting the Print YMC under K and Print K Only options
Step Procedure
1 • Select between the Print YMC Under K and Print K Only options. (Note:
When the Print YMC Under K option is selected, all black in the designated
areas will print with the Yellow (Y), Magenta (M) and Cyan (C) Ribbon panels
directly beneath the resin black (K) panel.)
OR
• Select this option if printing resin black text or bar codes onto a colored
background to provide a more gradual transition between the two.
2 Select Print K Only if printing resin black onto a white background to maximize
the sharpness of printed text and bar codes. (Note: When this option is
selected, all black in the designated areas will print only with the resin black (K)
panel.)
