If horizontal tab data is loaded and there is no right tab stop of the
current horizontal print position within the horizontal tab stops
specified in the horizontal tab data, this code is also converted to a
space code
Example 2:
C o l u m n 1 2 3 4 5 6 7 9 . . . . . 20 21 22 23 24 25 26
Horizontal tab stop
D a t a A B C D E F G H I A B C D E F
P r i n t i n g A B C D E F G H I . . . . . A B C D E F
(4) LF code
The LF code directs the printer to feed one line. If the printer is
receiving print data before receiving this code, it prints the data, then
feeds one line.
Example:
C o l u m n 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
D a t a K L M P Q R
P r i n t i n g A B C D E F G
H
P Q R
If the setup L.TERM is set to CR/FF, the printer does not return the
horizontal print position to column 1. However, if the is set to
PRTCMD, the printer returns the position to column 1 after printing.
(5) VT code
When receiving the VT code, the printer feeds forms up to the first
channel line specified from the operator panel.
If the printer is
receiving print data before receiving this code, it prints the data, then
feeds forms.
This channel can be selected from channels 2 to 12 by setting. F o r
example, if channel 2 is specified by the setup above, the printer skips
to channel 2 when receiving the VT code.
The printer can also perform the LF code function receiving the VT
code by setting.
6 17
