FUJITSU M304X User Manual

Page 65

Data Bit 1

Data Bit

Transferred

data

Undefined

Strobe

Busy

Acknowledge

Fault

A = 2.5 more

Note:

When receiving the DC3 code,

the printer goes offline and does not

issue the Acknowledge signal.

Figure

5.5 DC3 code receive timing

VFU command

code

Data

Bit

Data

Data Bit 8

Strobe

A = 2.5

Note:

The Busy signal is set to

1 each time FCB command code

and data

are sent.

Figure 5.6 Skip-15-Lines command receive timing chart

5 - 7
