(2) Forms container
If the forms catch on container lids when being fed, feed errors may
occur. Therefore arrange the lids as shown in Figure 2.9.
Allowable Unallowable
Figure 2.9 Forms container lids
Inside space between the forms and container should be 4 to 7 (0.16" to
0.28"). The bottom of the box must be flat. See Figure 2.10.
(Top view) (Side view)
Figure 2.10 Shape of the forms container
The forms container height must be 330.2 or less to be installed
in the hopper.
If the form length or folding dimension is more than the front and
rear doors must be open during operation.
2.5.2 Dimensions
This section describes dimensions of the forms, printing area, pin feed holes.
and perforations.
(1) Forms dimensions
Forms width: 76.2 to 431.8 to
Forms length: 76.2 to 381 (3" to 15")
2 12
