FUJITSU M304X User Manual
Page 33
CHAPTER 3 CONFIGURATION
The printer consists of the mechanical unit, control unit, forms rack, rear
door and cabinet.
The top cover and front door are included in the cabinet.
The operator panel,
control circuit board, and power supply are included in the
control unit.
Figure 3.1 shows their locations.
Rear door
Operator
Figure 3.1
Printer configuration
\ Front
door
3 - l
