2.6 Format Control Tape
The and 12-channel format control tapes are used for loading vertical
control data into the forms control buffer the printer using
the FCT unit. must conform to the following FCT specifications:
2.6.1 Medium quality
Medium used for the FCT should be:
Total thickness: 0.100 to 0.110 (0.0039" to 0.0043")
Light
transmittance:
5% less
The FCT made up of a polyester resin film and paper would be stronger at
tensile, tearing, and folding.
2.6.2 Dimensions
The FCT dimensions vary with the and The dimension must be
as shown in Figure 2.18.
2 19
