Audio Features (contd.)
Feature: Description:
Mixer • Output mixing of all audio sources: digitized sounds, FM
music, microphone, line in, CD audio, and PC speaker
• Input mixing sources: FM music, microphone, Stereo In, CD
audio, and PC speaker
• Multiple source recording and Left/Right channels swapping or
mixing
• 8-level volume control for digitized sounds, FM music,
microphone, Stereo In, CD audio, and master volume
• 4-level volume control for PC speaker
Built-in Power Amplifier • One watt with eight ohms speaker
MIDI Interface • Built-in MIDI interface for connection to external MIDI devices
• Sound Blaster and MPU-401 UART mode compatible
• MIDI time-stamp for multimedia extension
• Input buffer: 64-byte FIFO
Microphone Input • Automatic Gain Control (AGC) amplifier or fixed gain amplifier
• Input impedance: 600 ohms
• Sensitivity: 30 mVpp to 200 mVpp
Headphones Jack/Stereo
Out Jack • Impedance: 32 ohms
Sound Codec • High-performance, 16-bit stereo ADC/DAC
• 64 times over-sampling Delta-Sigma technology
• 85-dB dynamic range
• On-chip digital anti-aliasing and interpolation filters
POWER CONSUMPTION INFORMATION
Full Power mode 280 W
Off < 3 W*
* The power supply in your Vectra PC
continues to supply power to the CMOS
memory, even when switched off.
NOTE When the PC is turned off with the power button on
the front panel, the power consumption falls below 5
Watts, but is not zero. The special on/off method
used by this PC considerably extends the lifetime of
the power supply. To reach zero power consumption
in “off” mode, either unplug the PC from the power
outlet or use a power block with a switch. You should
be aware that, in this case, the PC will lose its time
settings within a few days.
