HP Vectra VE 5/series 2 - Manual (Page 95)

Feature: Description:
Accessory slots Three 32-bit PCI slots, one combo ISA/PCI slot, two 16-bit ISA
slots
Keyboard/Mouse HP keyboard with mini-DIN connector
HP mouse with mini-DIN connector
Characteristics: Description:
Weight (excluding
keyboard and display) 15 kilograms (33 pounds).
Dimensions 40.5 cm (D) by 21 cm (W) by 41.5 cm (H)
(15.95 inches by 8.27 inches by 16.34 inches).
Footprint 0.085 m2 (0.91 sq ft).
Storage temperature -40 °C to 70°C (-40 °F to 158 °F).
Storage humidity 8% to 80% (relative).
Operating temperature 5 °C to 40 °C (40 °F to 104 °F).
Operating humidity 15% to 80% (relative).
Acoustic noise emission < 40 db in the workplace under normal conditions as defined by
DIN 45635 T.19 and ISO 7779.
Power supply • Input voltage: 100-127 V ac, 200-240 V ac (switch-selectable)
• Input frequency: 50/60Hz
• Maximum power: 280 W continuous.
AUDIO FEATURES
Feature: Description:
Digitized Sounds • Sound Blaster 16, General MIDI, MPC2 Compliant
• Compatible with AdLib FM
• 16-bit and 8-bit stereo sampling from 5 kHz to 44.1 kHz
• 8-bit DMA transfer on channel 1 or 3, 16-bit DMA transfer on
channel 5 or 7
• 8-bit ADPCM decompression in hardware (2:1, 3:1, and 4:1)
• 16-bit software-based real-time audio compression/
decompression system with the following standards: Creative
ADPCM (16:4), CCITT A-law (16:8), CCITT m-law (16:8)
• Automatic dynamic filtering for digital audio recording and
playback
Music Synthesizer • 20-voice enhanced OPL3 FM music synthesis using four
operators
• 4 operator mode with 6 melodies and 5 percussions
or 2 operator mode with 15 melodies and 5 percussions
• Wavetable upgrade option for orchestral, 32-voice polyphony
(16-bit wave-sample synthesis)
