Chapter 5 Instruction Specifications
5-24
Item number Basic instructions-18 Name Logical block serial connection (ANB)
Ladder format Condition code Processing time ( µs) Remark
R7F4 R7F3 R7F2 R7F1 R7F0 Average Maximum
(See Function column) DER ERR SD V C
z z z z z
Instruction format Number of steps  
Condition Steps
ANB  0
Bit Word Double word
Usable I/O
X Y
R,
M
TD, SS,
CU, CT WX WY
WR,
WM TC DX DY
DR,
DM C
o
nstant
Other
Function
X00001 Y00100 LD X00001
LD R010
OR R011
ANB
LD M0020
AND M0021
OR M0022
ANB
OUT Y00100 R010 M0020 M0021
R011 M0022
This instruction is used to perform AND operation with respect to the logical operation blocks (dotted line area).
AN
B
