Chapter 5 Instruction specifications
5-116
[3] Address of sending area :
Address number and address type are configured in 2 words as below.
s+4
s+5
Type : WR → H000A
I/O No.: H0000 -
WM → H000C
[4] Reserved data size for data sending. : This is not actual data size but reserved size. Set it by "Word".
[5] Address of receiving area :
Address number and address type are configured in 2 words as below.
(Data format is as same as sending area.)
[6] Reserved data size for data receiving. : This is not actual data size but reserved size. Set it by "Word".
[7]
*1
Receiving data length :
If receiving data is found by data length, set this parameter by "Byte". The maximum size is 1,024 byte. If data is
more than 1,024 bytes or reserved area, TRNS command fails with DER="1".
[8]
*1
Start code :
If receiving data is found by start code, set this parameter.
b15 b7 b0
Start code (H00 - HFF)
= 0 : Start code disabled.
= 1 : Start code enabled.
[9] *1 End code :
If receiving data is found by end code, set this parameter.
b15 b7 b0
End code (H00 - HFF)
= 0 : End code disabled.
= 1 : End code enabled.
[10] Communication speed : [11] Communication format
Baud rate Value Format Value
300 bps H0000 7 bits, even parity, 2 stop H0000
600 bps H0001 7 bits, odd parity, 2 stop H0001
1,200 bps H0002 7 bits, even parity, 1 stop H0002
2,400 bps H0003 7 bits, odd parity, 1 stop H0003
4,800 bps H0004 8 bits, non parity, 2 stop H0004
9,600 bps H0005 8 bits, non parity, 1 stop H0005
19,200 bps H0006 8 bits, even parity, 1 stop H0006
38,400 bps H0007 8 bits, odd parity, 1 stop H0007
57,600 bps H0008
TR
N
S
0
(
d, s, t)
