HP 8080 ELITE BUSINESS User Manual
Page 98
CAUTION:
Hold the subpanel straight when you pull it away from the front bezel. Pulling the
subpanel away at an angle could damage the pins that align it within the front bezel.
12.
Reposition the bezel blanks within the subpanel in the proper orientation for the minitower
configuration.
13.
Reposition the subpanel (rotate it 90º) with the logo at the bottom, then snap it back into the
bezel.
Figure 5-62
Changing from a Desktop to a Minitower Configuration
14.
Replace the front bezel and computer access panel.
15.
Reconnect the power cord and turn on the computer.
16.
Lock any security devices that were disengaged when the computer access panel was removed.
86
Chapter 5 Removal and Replacement Procedures Convertible Minitower (CMT) Chassis
