Security Lock Provisions

NOTE:

For information on data security features, refer to the Desktop Management Guide and the

HP ProtectTools Security Manager Guide (some models) at

http://www.hp.com

The security locks displayed below and on the following pages can be used to secure the computer.

Installing a Security Lock

HP/Kensington MicroSaver Security Cable Lock

There are two cable lock slots on the rear of the computer. The slot next to the thumbscrew should be
used when there is no port cover. The slot on the far right should be used when a port cover is
installed.

Figure 7-1

Installing a Cable Lock with No Port Cover

Figure 7-2

Installing a Cable with a Port Cover Installed

144 Chapter 7 Removal and Replacement Procedures Ultra-Slim Desktop (USDT) Chassis
