Front bezel – HP 8080 ELITE BUSINESS User Manual
Page 108
Front Bezel
1.
Prepare the computer for disassembly (
Preparation for Disassembly on page 87
2.
Remove the access panel (
Computer Access Panel on page 95
).
3.
Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).
Figure 6-11
Removing the Front Bezel
To install the front bezel, reverse the removal procedure.
96
Chapter 6 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
