Front I/O, USB Assembly
The front I/O, USB assembly is mounted to the front of the chassis and is removed by pulling it away
from the chassis.
1. Prepare the computer for disassembly ( Preparation for Disassembly on page 31 ).
2. Remove the computer access panel ( Computer Access Panel on page 34 ).
3. Remove the front bezel ( Front Bezel on page 35 ).
4. Disconnect the three cables from the following system board connectors:
● Yellow connector labeled FRONT USB
● Green connector labeled FRONT USB2
● Blue connector labeled FRONT AUD
NOTE: The blue FRONT AUD connector is not located near the other two connectors
used for the front I/O assembly. See the image below for its location.
5. Remove the screw that secures the assembly to the front of the chassis (1).
Front I/O, USB Assembly 63
