Monitor
Connector and Icon
Pin Signal Pin Signal
1
2
3
4
Red Analog
Green Analog
Blue Analog
Not used
9
10
11
12
+5V (fused)
Ground
Not used
DDC Serial Data
5
6
7
8
Ground
Ground
Ground
Ground
13
14
15
Horizontal Sync
Vertical Sync
DDC Serial Clock
DisplayPort
Connector and Icon
TOP ROW BOTTOM ROW
Pin Signal Type Pin Name Pin Signal Type Pin Name
1
3
5
7
9
Ground
Out
Out
Ground
Out
Ground
GND
ML Lane 0 (p)
ML Lane 0 (n)
GND
ML Lane 1 (p)
2
4
6
8
10
In
CONFIG
CONFIG
GND
Out
Hot Plug Detect
CONFIG 1
CONFIG 2
GND
ML Lane 3 (p)
11
13
15
17
19
Out
Ground
Out
Out
Ground
ML Lane 1 (n)
GND
ML Lane 2 (p)
ML Lane 2 (n)
GND
12
14
16
18
20
Out
GND
I/O
I/O
PWR Out
ML Lane 3 (n)
GND
AUX CH (p)
AUX CH (n)
DP_PWR
Monitor 183
