5. Slide the new SODIMM into the socket at approximately a 30° angle (1) then press the SODIMM
down (2) so that the latches lock it in place.
Figure 7-15 Installing a SODIMM
NOTE: A memory module can be installed in only one way. Match the notch on the module
with the tab on the memory socket.
A SODIMM must occupy the XMM1 (top) socket.
6. Replace the SODIMM in the DIMM1 socket if it was removed.
7. Replace the access panel.
8. If the computer was on a stand, replace the stand.
9. Reconnect the power cord and turn on the computer.
10. Lock any security devices that were disengaged when the computer cover or access panel was
removed.
The computer automatically recognizes the additional memory when you turn on the computer.
156 Chapter 7 Removal and Replacement Procedures Ultra-Slim Desktop (USDT) Chassis
