Removing a Drive from a Drive Bay
CAUTION: All removable media should be taken out of a drive before removing the drive from the
computer.
1. Prepare the computer for disassembly ( Preparation for Disassembly on page 31 ).
2. Remove the computer access panel ( Computer Access Panel on page 34 ).
3. Disconnect the drive cables, as indicated in the following illustrations:
CAUTION: When removing the cables, pull the tab or connector instead of the cable itself to
avoid damaging the cable.
● If you are removing an optical drive, disconnect the power cable (1) and data cable (2) from
the back of the drive.
Figure 5-17 Disconnecting the Optical Drive Cables
50 Chapter 5 Removal and Replacement Procedures Convertible Minitower (CMT) Chassis
