Front I/O, Power Switch Assembly
The front I/O and power switch/LEDs are one assembly, attached to the front of the chassis. Push the
assembly into the chassis to remove.
1. Prepare the computer for disassembly ( Preparation for Disassembly on page 87 ).
2. Remove the access panel ( Computer Access Panel on page 95 ).
3. Remove the front bezel ( Front Bezel on page 96 ).
4. Remove the chassis fan ( Front Fan Assembly on page 129 ).
5. Rotate the drive cage to its upright position.
6. Disconnect the four cables from the system board as follows:
● Yellow connector labeled FRNT USB1
● Green connector labeled FRNT USB2
● Blue connector labeled FRNT AUD
● Black connector labeled PB/LED
7. Remove the screw that secures the assembly to the front of the chassis.
Figure 6-57 Removing the front I/O, power switch/LED assembly screw
