Using the Small Form Factor Computer in a Tower

Orientation

The Small Form Factor computer can be used in a tower orientation. The HP logo plate on the front
bezel is adjustable for either desktop or tower orientation.

Prepare the computer for disassembly (

Preparation for Disassembly on page 87

Orient the computer so that its right side is facing down and place the computer in the optional
stand.

Figure 6-67

Changing from Desktop to Tower Orientation

NOTE:

To stabilize the computer in a tower orientation, HP recommends the use of the

optional tower stand.

Lock any security devices that were disengaged when the access panel was removed.

NOTE:

Ensure at least 10.2 centimeters (4 inches) of space on all sides of the computer remains

clear and free of obstructions.

142 Chapter 6 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
