Power Switch Assembly
The power switch assembly is mounted to the front of the chassis and removed by pulling it away
from the chassis.
1. Prepare the computer for disassembly ( Preparation for Disassembly on page 31 ).
2. Remove the computer access panel ( Computer Access Panel on page 34 ).
3. Remove the computer access panel ( Front Bezel on page 35 ).
4. Disconnect the cable from the black system board connector labeled PB/LED.
5. Press downward on the tab (1) at the top of the assembly.
6. Rotate the top of the assembly downward (2), and then pull it away from the chassis while
threading the wires through the hole in the front of the chassis.
Figure 5-38 Removing the power switch assembly
To install the power switch assembly, reverse the removal procedure.
Power Switch Assembly 65
