Cable Management
Always follow good cable management practices when working inside the computer.
● Keep cables away from major heat sources like the heat sink.
● Do not jam cables on top of expansion cards or memory modules. Printed circuit cards like these
are not designed to take excessive pressure on them.
● Keep cables clear of sliding or moveable parts to prevent their being cut or crimped when the
parts are moved.
● Do not bend any cable sharply. A sharp bend can break the internal wires.
● Never bend a SATA data cable tighter than a 30 mm (1.18 in) radius.
● Never crease a SATA data cable.
● Do not rely on components like the drive cage, power supply, or computer cover to push cables
down into the chassis. Always position the cables to lay properly by themselves.
Cable Connections
System board connectors are color-coded to make it easier to find the proper connection.
System Board Connections
System Board Connector Connector Name Connector Color Description
P9 CHFAN1 Maroon Front chassis fan
P11 CHFAN2 Brown Rear chassis fan
P6 SPRK White Internal speaker
P61 SATA1 White Optical data
P125 HSENSE White Hood sensor
P151 BOOST Black ReadyBoost module
P160 N/A Black Optical power
P160 N/A Black Optical power
Replacing the Optical Drive
The Ultra-Slim Desktop uses a slimline Serial ATA (SATA) optical drive.
Removing the Existing Optical Drive
1. Prepare the computer for disassembly ( Preparation for Disassembly on page 143 ).
2. If the computer is on a stand, remove the computer from the stand and lay the computer down.
3. Remove the computer access panel ( Computer Access Panel on page 150 ).
