Hitachi L100 User Manual
Page 86
“C” Group: Intelligent Terminal Functions
Conf
igur
in
g
Dr
iv
e P
a
ra
m
e
ter
s
3–30
15
SFT
Software Lock
ON
The keypad and remote programming
devices are prevented from changing param-
eters
OFF
The parameters may be edited and stored
16
AT
Analog Input
Voltage/current
Select
ON
Terminal OI is enabled for current input
(uses terminal L for power supply return)
OFF
Terminal O is enabled for voltage input (uses
terminal L for power supply return)
18
RS
Reset Inverter
ON
The trip condition is reset, the motor output
is turned off, and powerup reset is asserted
OFF
Normal power-on operation
19
PTC
PTC Thermistor
Thermal Protection
ANLG When a thermistor is connected to terminals
5 and L, the inverter checks for over-
temperature and will cause trip event and
turn off output to motor
OPEN A disconnect of the thermistor causes a trip
event, and the inverter turns off the motor
Input Function Summary Table
Option
Code
Terminal
Symbol
Function Name
Description
