L100 Inverter
Appendi
x B
B–11
F-32
Frequency arrival
threshold during
acceleration
ARV ACC 000.0Hz
ARV ACC 000.0Hz
Frequency arrival
threshold during
deceleration
ARV DEC 000.0Hz
ARV DEC 000.0Hz
F-33
Overload previous level
OV Load 01.40A
(rated current)
OV Load 01.40A
(rated current)
Error overload (thresh-
old) for PID loop
OV PID 003.0%
OV PID 003.0%
F-34
Intelligent input 1
function code
IN-TM 1 FW
IN-TM 1 FW
Intelligent input 2
function code
IN-TM 2 RV
IN-TM 2 RV
Intelligent input 3
function code
IN-TM 3 CF1
IN-TM 3 AT
Intelligent input 4
function code
IN-TM 4 CF2
IN-TM 4 USP
Intelligent input 5
function code
IN-TM 5 RS
IN-TM 5 RS
Intelligent input 1
NO/NC (active state)
IN-TM O/C-1 NO
IN-TM O/C-1 NO
Intelligent input 2
NO/NC (active state)
IN-TM O/C-2 NO
IN-TM O/C-2 NO
Intelligent input 3
NO/NC (active state)
IN-TM O/C-3 NO
IN-TM O/C-3 NO
Intelligent input 14
NO/NC (active state)
IN-TM O/C-4 NO
IN-TM O/C-4 NC
Intelligent input 5
NO/NC (active state)
IN-TM O/C-5 NO
IN-TM O/C-5 NO
F-35
Intelligent output 11
function code
OUT-TM 1 FA1
OUT-TM 1 FA1
Intelligent output 12
function code
OUT-TM 2 RUN
OUT-TM 2 RUN
Relay output NO/NC
(active state)
OUT-TM O/C-A NC
OUT-TM O/C-A NC
Intelligent output 11
NO/NC (active state)
OUT-TM O/C-1 NO
OUT-TM O/C-1 NO
Intelligent output 12
NO/NC (active state)
OUT-TM O/C-2 NO
OUT-TM O/C-2 NO
F-36
Carrier frequency setting CARRIER 05.0kHz
CARRIER 05.0kHz
Function Mode Setup
Displayed Default Setting
User Setting
Func.
Code
Name
-FE (Europe)
-FU (USA)
