2–13
Determination of Wire and Fuse Sizes
The maximum motor currents in your application determines the recommended wire
size. The following table gives the wire size in AWG. The “Power Lines” column applies
to the inverter input power, output wires to the motor, the earth ground connection, and
any other component shown in the system wiring diagram on page 2–5. The “Signal
Lines” column applies to any wire connecting to the two green 7 and 8-position connec-
tors just inside the front panel half-door.
Note 1: Field wiring must be made by a UL-listed and CSA-certified closed-loop
terminal connector sized for the wire gauge involved. Connector must be fixed by using
the crimping tool specified by the connector manufacturer.
Note 2: Be sure to consider the capacity of the circuit breaker to be used.
Note 3: Be sure to use larger wires for the power lines if the distance exceeds 20 meters.
(*) Use 18 AWG / 0.75 mm
2
wire for the alarm signal wire (AL0, AL1, AL2 terminals).
Motor Output
(kW/HP)
Inverter Model
Wiring
Applicable
equipment
kW HP Power Lines Signal Lines
Fuse (class J)
rated 600V
0.2 1/4 L100-002NFE/NFU
AWG16 / 1.3 mm 2
(*)
18 to 28 AWG /
0.14 to 0.75 mm 2
shielded wire
10A 0.4 1/2 L100-004NFE/NFU
0.55 3/4 L100-005NFE
.75 1 L100-007NFE/NFU
AWG14 / 2.1 mm 2 15A
1.1 1 1/2 L100-011NFE
1.5 2 L100-015NFE/NFU
AWG12 / 3.3 mm 2
20 A (single ph.)
15A (three ph.)
2.2 3 L100-022NFE/NFU
AWG10 / 5.3 mm 2
30A (single ph.)
20A (three ph.)
3.7 5 L100-037LFU AWG12 / 3.3 mm 2 30A
5.5 7 1/2 L100-055LFU AWG10 / 5.3 mm 2 40A
7.5 10 L100-075LFU AWG8 / 8.4 mm 2 50A
0.4 1/2 L100-004HFE/HFU
AWG16 / 1.3 mm 2
3A
0.75 1 L100-007HFE/HFU 6A
1.5 2 L100-015HFE/HFU
10A
2.2 3 L100-022HFE/HFU
3.0 4 L100-030HFE
AWG14 / 2.1 mm 2 15A
4.0 5 L100-040HFE/HFU
5.5 7 1/2 L100-055HFE/HFU
AWG12 / 3.3 mm 2
20A
7.5 10 L100-075HFE/HFU 25A
