Hitachi L100 - Manual (Page 82)

“B” Group: Fine Tuning Functions
Conf
igur
in
g
Dr
iv
e P
a
ra
m
e
ter
s
3–26
B82 Start frequency
adjustment Sets the starting frequency for
the inverter output, range is 0.5
to 9.9 Hz ✘ 0.5 Hz F-02 FMIN.
B83 Carrier frequency
setting Sets the PWM carrier (internal
switching frequency), range is
0.5 to 16.0 kHz ✘ 5 kHz F-36 CARRIER
B84 Initialization mode
(parameters or trip
history) Select the type of initialization
to occur, two option codes:
00 ...Trip history clear
01 ...Parameter initialization ✘ 00 — F-38 INIT
MODE
B85 Country code for
initialization Select default parameter values
for country on initialization,
four options, option codes:
00 ...Japan version
01 ...Europe version
02 ...US version
03 ...reserved (do not set) ✘ 01/02 — F-38 INIT SEL
B86 Frequency scalar
conversion factor Specify a constant to scale the
displayed frequency for D07
monitor, range is 0.1 to 99.9 ✘ 1.0 — Mon. /HZ
B87 STOP key enable Select whether the STOP key
on the keypad is enabled, two
option codes:
00 ...enabled
01 ...disabled ✘ 00 — F-28 STOP-SW
B88 Resume on FRS
cancellation mode Selects how the inverter
resumes operation when the
free-run stop (FRS) is
cancelled, two options:
00 ...Restart from 0Hz
01 ...Restart from frequency
detected from real speed of
motor ✘ 00 — F-10 RUN FRS
B89 Data select for digital
operator OPE-J Select the monitoring data to
send to the hand-held digital
operator, seven option codes:
01 ...Output frequency (D01)
02 ...Output current (D02)
03 ...Motor direction (D03)
04 ...PID PV feedback (D04)
05 ...Input states for input
terminals (D05)
06 ...Output states for output
terminals (D06)
07 ...Scaled output frequency
(D07) ✔ 01 — Mon. PANEL
“B” Function
Run-
time
Edit
Defaults DOP,DRW,DOP+
Func.
Code
Name Description
EU/
US
Units
Func.
Code
Name
