L100 Inverter
Appendi
x B
B–7
Parameter Settings for DOP/DRW/DOP Plus
L100 series inverters provide many functions and parameters which can be configured
by the user. We recommend that you record all parameters which have been edited, in
order to help in troubleshooting or recovery from a loss of parameter data.
Monitor Mode Parameters
Inverter model
MFG. No.
L100
}
This information is printed
on the specification label
located on the right side of
the inverter.
Monitor Mode Setup Displayed Default Setting
User Setting
Func.
Code
Name -FE (Europe) -FU (USA)
Mon. Frequency setting TM 000.0 0.0Hz TM 031.6 0.0Hz
Acceleration time ACC1 0010.0s ACC1 0010.0s
Deceleration time DEC1 0010.0s DEC1 0010.0s
Frequency setting F-SET-SELECT TRM F-SET-SELECT TRM
Frequency source select F/R-SELECT TRM F/R-SELECT TRM
Scaled frequency value /Hz01.0 0.00 /Hz01.0 0.00
Output current display Im 0.0A 0.0% Im 0.0A 0.0%
Reactive current display IO 0.00A IO 0.00A
Manual torque boost V-Boost code 11 V-Boost code 11
Torque boost frequency
setting V-Boost F 10.0% V-Boost F 10.0%
Torque boost mode V-Boost Mode 0 V-Boost Mode 0
Output voltage gain adj. V-Gain 100% V-Gain 100%
Jog frequency Jogging 1.00Hz Jogging 1.00Hz
Jog mode select Jog Mode 0 Jog Mode 0
Analog adjustment ADJ 080 ADJ 080
Panel display selection PANEL d01 PANEL d01
Terminal monitor TERM LLL LLLLLL TERM LLL LLLLLL
