L100 Inverter
Confi
gur
in
g
Dr
iv
e P
a
ra
mete
rs
3–29
Summary Table - this table shows all fifteen intelligent input functions at a glance.
Detailed descriptions of these functions, related parameters and settings, and example
wiring diagrams are in Chapter 4, starting on page 4–6.
Input Function Summary Table
Option
Code
Terminal
Symbol
Function Name Description
00 FW Forward Run/Stop ON Inverter is in Run Mode, motor runs forward
OFF Inverter is in Stop Mode, motor stops
01 RV Reverse Run/Stop ON Inverter is in Run Mode, motor runs reverse
OFF Inverter is in Stop Mode, motor stops
02 CF1 Multi-speed select,
Bit 0 (LSB) ON Binary encoded speed select, Bit 0, logical 1
OFF Binary encoded speed select, Bit 0, logical 0
03 CF2 Multi-speed select,
Bit 1 ON Binary encoded speed select, Bit 1, logical 1
OFF Binary encoded speed select, Bit 1, logical 0
04 CF3 Multi-speed select,
Bit 2 ON Binary encoded speed select, Bit 2, logical 1
OFF Binary encoded speed select, Bit 2, logical 0
05 CF4 Multi-speed select,
Bit 3 (MSB) ON Binary encoded speed select, Bit 3, logical 1
OFF Binary encoded speed select, Bit 3, logical 0
06 JG Jogging ON Inverter is in Run Mode, output to motor
runs at jog parameter frequency
OFF Inverter is in Stop Mode
09 2CH 2-stage Acceleration
and Deceleration ON Frequency output uses 2nd-stage accelera-
tion and deceleration values
OFF Frequency output uses standard acceleration
and deceleration values
11 FRS Free-run Stop ON Causes output to turn off, allowing motor to
free run (coast) to stop
OFF Output operates normally, so controlled
deceleration stops motor
12 EXT External Trip ON When assigned input transitions Off to On,
inverter latches trip event and displays E12
OFF No trip event for On to Off, any recorded trip
events remain in history until Reset
13 USP Unattended Start
Protection ON On powerup, the inverter will not resume a
Run command (mostly used in the US)
OFF On powerup, the inverter will resume a Run
command that was active before power loss
