Hitachi L100 - Manual (Page 159)

Parameter Settings for DOP/DRW/DOP Plus
Appendi
x B
B–12
F-37 Monitor signal selection MONITOR A-F MONITOR A-F
F-38 Initialization country
code for default settings INIT SEL EUR INIT SEL USA
Debug mode display
selection INIT DEBG OFF INIT DEBG OFF
Motor rotation direction INIT DOPE FWD INIT DOPE FWD
Initial mode selection INIT MODE TRP INIT MODE TRP
F-43 PID loop enable PID SW OFF PID SW OFF
PID proportional gain PID P 1.0 PID P 1.0
PID integral gain PID I 001.0s PID I 001.0s
PID derivative gain PID D 000.0 PID D 000.0
PID scale factor setting PID CONV 01.00 PID CONV 01.00
PID input (PV) selection PID INPT CUR PID INPT CUR
Function Mode Setup Displayed Default Setting
User Setting
Func.
Code
Name -FE (Europe) -FU (USA)
