Footnotes for the preceding tables and the table on the following page:
*1: The protection method conforms to JEM 1030.
*2: The applicable motor refers to Hitachi standard 3-phase motor (4-pole). To use other
motors, care must be taken to prevent the rated motor current (50/60 Hz) from exceeding the
rated output current of the inverter.
*3: The output voltage decreases as the main supply voltage decreases (except for use of the
AVR function). In any case, the output voltage cannot exceed the input power supply
voltage.
*4: To operate the motor beyond 50/60 Hz, consult the motor manufacturer about the maximum
allowable rotation speed.
*5: The braking torque via capacitive feedback is the average deceleration torque at the shortest
deceleration (stopping from 50/60 Hz as indicated). It is not continuous regenerative braking
torque. And, the average deceleration torque varies with motor loss. This value decreases
when operating beyond 50 Hz. Note that a braking unit is not included in the inverter. If a
large regenerative torque is required, the optional regenerative braking unit should be used.
*6: The frequency command is the maximum frequency at 9.8V for input voltage 0 to 10 VDC,
or at 19.6 mA for input current 4 to 20 mA. If this characteristic is not convenient for your
application, contact your Hitachi sales representative.
*7: If operating the inverter in an ambient temperature of 40–50
°
C, reduce the carrier frequency
to 2.1 kHz, derate the output current by 80%, and remove the top housing cover. Note that
removing the top cover will nullify the NEMA rating for the inverter housing.
*8: The storage temperature refers to the short-term temperature during transport.
*9: Conforms to the test method specified in JIS C0911 (1984). For the model types excluded in
the standard specifications, contact your Hitachi sales representative.
*10:The input voltage of xxLFU is 230V.
Item 400V Class Specifications
L100 inverters, 400V models 004HFE
004HFU
007HFE
007HFU
015HFE
015HFU
022HFE
022HFU
030HFE
—
040HFE
040HFU
055HFE
055HFU
075HFE
075HFU
Applicable motor size *2 kW 0.4 0.75 1.5 2.2 3.0 4.0 5.5 7.5
HP 1/2 1 2 3 4 5 7.5 10
Rated capacity (460V) kVA *10 1.1 1.9 3.0 4.3 6.2 6.8 10.4 12.7
Rated input voltage 3-phase: 380 to 460V ±10%, 50/60 Hz ±5%
Rated input current (A) 2.0 3.3 5.0 7.0 10.0 11.0 16.5 20.0
Rated output voltage *3 3-phase: 380 to 460V (corresponding to input voltage)
Rated output current (A) 1.5 2.5 3.8 5.5 7.8 8.6 13 16
Braking Dynamic braking,
approx. % torque,
(short time, stopping
from 50 / 60 Hz) *5 100%:
≤
50Hz
50%:
≤
60Hz
40%:
≤
50Hz,
20%:
≤
60Hz
20%:
≤
50Hz
20%:
≤
60Hz
Capacitive feedback type, dynamic braking unit and braking resistor optional,
individually installed
DC braking Variable operating frequency, time, and braking force
Weight kg / lb 1.3/2.9 1.7/3.7 1.7/3.7 2.8/6.2 2.8/6.2 2.8/6.2 5.5/12.1 5.7/12.5
