3.2.5.10 Upper Frame Removal

1. Remove the printer mechanism. (See section 3.2.4.)

2. Remove the carriage unit. (See section 3.23.2.)

3. Remove the E-ring securing

to

sub frame; then remove the knob with the

knob shaft from the side frame (R).

4. Remove the 5 CBN

screws s

the upper frame to both side frames or the sub

frame. Then remove the upper frame with 4

support rollers.

I

Q

Tension Spring

Knob

\ , U p p e r F r a m e

E-ring

3-20. Upper Frame Removal

I

3-16

Rev.
