The Stylus Color printer has a special printing mode, microwave mode, for printing raster
graphics. This printing mode can be selected from the custom driver. Using the microwave mode
can improve the quality of output because it
tes the banding that can sometimes
normal mode. In microwave mode, the paper feed is performed after each print pass,
thus eliminating the pitch variation as the paper feed that causes the banding.
Microwave print mode is available for both 360-and resolution.
■ Normal mode
Normally the printer uses all nozzles for printing and each print line is completed in one pass.
But if the image data contains both
e and color in a single print line, the printer
the line in four passes even for monochrome printing ( 1/360 x 4 line because if
the image data contains color in a single print line, it uses only 16 nozzles in row A of the black
head.
Microwave mode
In microwave mode, the printer the whole image as a single image rather than as
continual lines. In this mode, the printer uses only 15 nozzles of row A of the nozzles (#1 to
#lS). After printing the first pass, the printhead moves to a new position 15/360 inch forward.
The printer repeats this sequence until it finishes printing the whole image. In microwave
mode the printing starts from the under nozzle (#57 pin).
Ist
1/90 inch
#5
Feed
1/360 (1/720) inch line feed
Paper (bottom
r
I
I
(#61 Not
I
#57
1/120”
#45
1/90”
#49
#53
#57
#57
#29
#45
#33
#49
#37
#53
#41
#57
1/360”
Final
#57
#29
#45
#13
#33
#49
#17
#37
#53
821
#41
#57
Figure 2-4. Microwave Mode Operation
.
