Epson 4003353 User Manual
Page 28
Stylus
1.5.4 Printer Mechanism
The
printer mechanism is equipped with a 64-black
and M-color
on the carnage unit. Resolution of 720 dpi is possible with special (non-absorbent) paper.
The ink system has both a black pump unit and a
pump unit. Waste ink from each
is made to flow into the individual caps. Power for the pump system and paper feed system is
supplied from the paper feed motor.
Figure 1-12. Printer Mechanism
1.5.5 Housing
The Stylus Color housing consists of the printer cover, uppercase, and the lowercase.
Attached to the housing
separator.
are the front paper support
ejected paper support
II
A
Case
L
Lower Case
Figure 1-13. Housing
with paper
4
1-20
Rev. A
