MVI69-101S ♦ CompactLogix or MicroLogix Platform Reference
IEC 60870-5-101 Slave Communication Module
Page 136 of 149 ProSoft Technology, Inc.
March 16, 2009
<125> := Segment F_SG_NA_1
<126> := Directory F_DR_TA_1
Basic Application Functions
Station initialization
(Station-specific parameter)
⌧ Remote initialization
General Interrogation
(System- or station-specific parameter)
⌧ global
⌧ group 1 ⌧ group 7 ⌧ group 13
⌧ group
2
⌧ group
8
⌧ group
l4
⌧ group 3 ⌧ group 9 ⌧ group 15
⌧ group 4 ⌧ group 10 ⌧ group 16
⌧ group 5 ⌧ group 11
⌧ group 6 ⌧ group 12
Addresses per group have to be defined
Clock synchronization
(Station-specific parameter)
⌧ Clock synchronization
Command transmission
(Object-specific parameter)
⌧ Direct command transmission ⌧ Select and execute
command
⌧ Direct set point command transmission ⌧ Select and execute
set point command
⌧ C_SE_ACTTERM used Note 2
⌧ No additional definition
⌧ Short pulse duration (duration determined by a system parameter in the
outstation)
Note 4
⌧ Long pulse duration (duration determined by a system parameter in the
outstation)
Note 4
⌧ Persistent
output
