Rugged Cams Vertex & Vertex RTH User Manual

Page 55

Select the motion detection sensitivity.

①

Select {Event} {Moti.} {Sensitivity} for the channel using the arrow keys and the

Menu button.

②

On the selection window, select the sensitivity using the arrow keys and the Select

button.

To set all channels at the same time, go to the top of the {Motion} column and press the

Select button.

Method of Setting the Sensitivity

Current sensitivity levels -- Lowest/Low/Middle/High/Highest -- indicate the proportion
of pixels within a block for which motion was detected. Therefore, the higher the
selected level is, the faster the motion can be detected.

(2) Sensor

This sets the detection of input made by external sensors interworking with the system. Up
to 16 external sensors can be set. When a signal of an external sensor is detected, the
video of the corresponding channel will be recorded.

①

Select {Event} {Sens.} for the channel using the arrow keys and the Select button.

②

On the selection window, select an external sensor channel using the arrow keys and

the Select button.

③

Select {Event} {Sens.} {Sensor Type} for the channel using the arrow keys and

the Menu button.

④

On the selection window, select the sensor type using the arrow keys and the Select

button.

To set all channels at the same time, go to the top of the {Sens} column and press the

Select button.

Normal Close (NC): Normally closed; opens when a signal is received
Normal Open (NO): Normally open; closes when a signal is received

(3) Sound

This detects sound inputted by an external source interworking with the system. Up to 16
audio inputs linked to the system may be set. If an external audio input signal is detected,
the video for the corresponding channel will be recorded. Each channel can detect 1 ~ 16
external audio devices.
