24
4-4 Audio Recording and Playback
4-4-1 Setting up the Audio Recording
① On the real-time monitoring screen, select {Live Menu} {Main Setup}.
② The main setup window will then appear as shown in Figure 5-1.
③ Select {Recording Setup} {Recording} {Audio} using the arrow keys and the
Select button.
④ Set up the audio.
4-4-2 Audio Live
① On the real-time monitoring screen, select {Live Menu} {Control} {Audio}.
② Select the audio channel.
4-5 Viewing System Information and Changing the Display Setup
Basic system information is displayed as shown in Figure 4-3.
Event Detect Channel
No Event Channel Sixteen-split View
Nine-Split View
Quad-Split View
Single-Channel View
Live or Playback Time Rotation
[Figure 4-3. Recording Status Window]
