14
2-2-2 Connection of Other Devices
Connect the PTZ controller cable, audio input/output, network, and sensors as shown
below.
.
Connected Device DVR Terminal
1 PTZ Camera RS485
2 SPOT Monitor(CCTV Monitor) SPOT
3 Mike / Speaker Audio Input / Audio Output
4 LAN Cable Ethernet
5 Sensor / Relay DIO (Digital Input/Output)
1) PTZ Camera
①
For the PTZ camera, connect the control cable of the PTZ camera to the terminal block
on the rear side of the DVR.
② Connect the RS485 wire to the terminal block on the rear side of the DVR. Connect
TRX+ and TRX-.
2) SPOT Monitor
The Spot monitor is a CCTV monitor that displays events.
SPOT ※ : The Spot monitoring function displays video from the channel detecting an
event (motion, sensor, or sound) in full screen. Events are checked every second. If
events are detected from multiple channels, the video from the channel with the latest
event is displayed.
3) Audio Input/output
Audio ports are basically provided; 4/8/ or16 input lines and 1 output line is supported.
4) Sensor/Relay
Connect to the rear side of the product using the cable.
Sensor Input Relay Output
16ch DVR 16 4
8ch DVR 8 2
4ch DVR 4 1
