Rugged Cams Vertex & Vertex RTH User Manual

Page 54

(5) Audio

Used to set the recording for the external audio input linked to the system

①

Select {Recording} {Audio} for the channel using the arrow keys and the Select

button.

②

On the selection window, select whether to record audio or not.

To set all channels at the same time, go to the top of the {Audio} column and press the

Select button.

3) Event

(1)

Motion

This function detects the movement of images. Detection settings include All, Partial, and Off.
The default value is Off, however.

Full

Detects all movements of images in each channel on the entire screen

①

Select {Event} {Moti.} for the channel using the arrow keys and the Select button.

②

On the selection window, select All.

Partial

Motion is detected in the user-defined areas of an image only.

①

Select {Event} {Moti.} for the channel using the arrow keys and the Select button.

②

On the selection window, select Partial.

③

The grid will then be displayed on the screen.

④

Select the area where motions will be detected using the arrow keys and the Select

button.

⑤

Select the zone and press the [ESC] button.

Method of Selecting the Zone

1) To view the zone set in yellow, press the [Select] button.
2) Set the zone using the arrow buttons and press the [Select] button.
3) Once set, the zone is displayed in green.
※

The [Select] button supports toggling.

Off

Motion detection in the video is disabled.
