3) Focus Control
①
To shift to focus control mode, press the PTZ button again in PTZ Zoom In/Out mode.
②
Use the arrow (▲▼) buttons.
③
To change the screen split in focus control mode, select {Menu} {Display Setting}
and shift to screen split mode.
4) Preset
Used to store the horizontal/vertical/extended/focus settings of the PTZ camera
①
To shift to Preset mode, press the Select button in Horizontal/Vertical PTZ Rotation,
Zoom In/Out, or Focus Control mode.
②
In PTZ Preset mode, select the Preset mode using the arrow keys and the Select button.
③
Numbers between 1 and 8 can be assigned.
④
After presetting is completed, the set numbers are displayed in blue, and the PTZ
setting status with the set number will be stored.
5) Using the Preset Function
In Vertical/Horizontal PTZ rotation, Zoom In/Out, and Focus Control modes, use the
numeric buttons.
6) Using the Tour feature
※
For more information on setting the Tour feature, select {Additional Setup} -> {PTZ Setup}
-> {Tour}.
①
After the Tour is set, No. 9 or No. 0 will be displayed in blue.
②
In Vertical/Horizontal PTZ Rotation, Zoom In/Out, or Focus Control mode, use the
numeric button 9 or 0.
③
To disable the Tour feature, press the currently enabled Tour numbers (9 and 0).
Tour 1
Set to 9.
Tour 2
Set to 0.
7) Controlling the PTZ Speed
①
Adjust the PTZ speed using the Up/Down button.
②
Speed is set between 1 ~ maximum speed.
③
The maximum speed differs for each PTZ model.
