4. If you are removing an option card that controls a mouse, you
need to change the setting of jumper J2 on the main system
board. If you are removing a display adapter card, you may
need to change the settings of jumpers J1 and J4. See page
4-4 for instructions.
5. Replace the cover. See Chapter 3 for instructions. Then see
“Post-installation Setup” at the end of this chapter.
Using the Alternate VGA Interface
Your computer includes an alternate VGA interface on the
main system board. This feature allows you to install a
high-resolution graphics adapter card in one of the option slots
for your VGA monitor and still access the standard VGA
signals provided by your main system board circuitry.
To connect the graphics adapter card interface to the alternate
VGA interface, follow these steps:
1. Remove the computer’s cover as described in Chapter 3.
2. Set jumper J1 on the main system board to B to disable the
built-in VGA display adapter. See “Changing the Jumper
Settings” on page 4-4 if you need instructions.
3. If you have not already done so, follow the instructions
above to install the graphics adapter card in your computer.
4-16 Installing and Removing Options
