Page 35
C o n f i g u r a t i o n a n d O p e r a t i o n
Page 36
Operating Instructions Powador 16.0 TR3, 18.0 TR3_EN
Country-
spec. setting
Menu
level
Display/
Setting
Action in this menu/meaning
All countries
0
1
2
3
1
Grnd fl t monitor
One pole of the PV generator is grounded in the device
using a fuse. The ground fault monitor is triggered in
the event of a ground fault in the generator. This pre-
vents possible damage to the modules.
NOTICE:
Activate ground fault monitoring only if you have
grounded one pole of the PV generator (see section
7.2.3 on page 22).
Activate or deactivate ground fault monitoring.
0
1
2
3
1
Const. volt. ctrl
Lets you deactivate the MPP seek mode in order to
operate the inverter with a constant DC voltage.
Activate or deactivate MPP seek mode.
Set value for constant voltage control (200 - 510 V).
DE
MSp.
0
1
2
3
1
Overvoltage shutd.
Specify the switch-off threshold for overvoltage
shutdown.
0
1
2
3
1
Undervoltage
shutd.
Specify the switch-off threshold for fast undervolt-
age shutdown.
Specify the switch-off threshold for slow undervolt-
age shutdown.
0
1
2
3
1
Activate FRT
The inverter supports dynamic grid stabilization (Fault
Ride-Through) in accordance with the BDEW Medium
Voltage Directive.
Specify constant k.
Specify the dead band.
Activate or deactivate FRT.
0
1
2
3
1
Idle power
Open the menu: Press the right arrow button or the
OK button.
0
1
2
3
2
cos-phi
specifi cation
Confi gure power factor.
If a power factor not equal to 1 is selected: Select
the type of phase shift (inductive/capacitive).
0
1
2
3
2
Q specifi cation
Set the idle power Q (in %) to a fi xed value.
Select the type of phase shift (inductive/capacitive).
0
1
2
3
2
cos-phi(P/Pn)
Open the menu: Press the right arrow button or the
OK button.
0
1
2
3
3
Number of
support points
This option defi nes how many support points can be
defi ned in the subsequent menu.
Specify the number of support points for the idle
power characteristic curve.
0
1
2
3
3
1. Support point
Specify the power factor for the fi rst, second, ...
support point
If a power factor not equal to 0 is selected: Select
the type of phase shift (inductive/capacitive).
0
1
2
3
3
2. Support point...
