C o n f i g u r a t i o n a n d O p e r a t i o n
Operating Instructions Powador 16.0 TR3, 18.0 TR3_EN Page 33
Country-
spec. setting
Menu
level
Display/
Setting
Action in this menu/meaning
All countries
0 1 2 3 1 Day display
Displays the recorded operating data graphically.
1. Select the measured value to be displayed.
Supported measured values:
• Grid power P(grid)
• DC power per string P(PV) 1-2
• DC voltage per string U(PV) 1-2
• Unit temperature
2. Select a date.
3. Press the OK button.
» The display shows the selected data.
 Press any button to return to the previous menu.
0 1 2 3 1 Month display
Displays the recorded operating data graphically.
1. Select a date.
2. Press the OK button.
» The display shows the selected data.
 Press any button to return to the previous menu.
0 1 2 3 1 Year display
Displays the recorded operating data graphically.
1. Select a date.
2. Press the OK button.
» The display shows the selected data.
 Press any button to return to the previous menu.
0 1 2 3 1 Save to USB
In this menu, you can export the saved operating data
to a connected USB storage device.
↻ You have connected a USB storage device to the
inverter.
1. Select the data to be exported (year, month or day)
with the 4-way button.
2. Press the OK button.
» The inverter writes the data to the USB storage
device.
All countries
0 1 2 3 0 “Settings” menu
 Open the menu: Press the right arrow button or the
OK button.
0 1 2 3 1 Language  Select the desired language for the user interface.
0 1 2 3 1 Def. total yield
You can set the total yield to any value, for example,
when you have received a replacement unit and want to
continue the recording from the present value.
 Select the “Save” button and confi rm with the OK
button.
